ANSI/ESD S8.1-2017

ESD Association Standard for the Protection of Electrostatic Discharge Susceptible Items – Symbols – ESD Awareness

The purpose of this document is to standardize commonly available and in-use symbols and to clarify the meaning of each of these symbols.

The correct usage of symbols will eliminate confusion between symbols that indicate that an item or material is ESD susceptible and those that indicate that an item is designed to afford some degree of ESD protection. This symbol standard is developed in accordance with international graphical guidelines and standards.

ESD Susceptibility Symbol

ESD Protective Symbol

Common Point Ground Symbol

Table of Contents
